Below are the list for cable tray installation man hour which include cable tray, cable tray cover; cable tray fittings such as 90 degree horizontal elbow, 90 degree vertical elbow, horizontal tee, horizontal cross, and reducer. It also include man hours for installation of cable tray accessories such as connector plates, expansion joint, drop out, cable separator and blind end.
For other reference material price list for electrical works and installation:
– Generator set price list, please check the link: GENSET PRICE LIST
– Manual transfer switch price list, please check the link: MTS PRICE LIST
– Automatic transfer switch price list, please check the link: ATS PRICE LIST
– Cable tray price list, please check the link: CABLE TRAY PRICE LIST
– IMC conduit price list, please check the link: IMC CONDUIT PRICE LIST
– PVC conduit price list, please check the link: PVC CONDUIT PRICE LIST
– THHN wire price list, please check the link: THHN WIRE PRICE LIST
– Royal cord wire price list, please check the link: ROYAL CORD PRICE LIST
– Liquid tight flexible conduit price list, please check the link: LTFC PRICE LIST
– Electrical accessories price list, please check the link: ELECTRICAL ACCESSORIES PRICE LIST
For electrical works installation man hours reference:
– Wires and conduit installation man hour, please check the link: ELECTRICAL INSTALLATION MAN HOURS
– Cable tray installation man hour, please check the link: CABLE TRAY INSTALLATION MAN HOURS
CABLE TRAY INSTALLATION MAN HOURS
CABLE TRAY
| Width of Cable Tray | Manhours per Linear Meter | ||
|---|---|---|---|
| Ladder Cable Tray | Cover for Cable Tray | ||
| 900 | mm | 1.98 | 2.71 |
| 750 | mm | 1.62 | 1.80 |
| 600 | mm | 1.44 | 0.90 |
| 450 | mm | 1.26 | 0.72 |
| 300 | mm | 1.19 | 0.54 |
| 200 | mm | 1.08 | 0.43 |
| 150 | mm | 0.90 | 0.43 |
FITTINGS
| Width of Cable Tray | Manhours per Linear Meter | |||||
|---|---|---|---|---|---|---|
| 90 deg Horizontal Elbow | 90 deg Vertical Elbow | Horizontal Tees | Horizontal Cross | Reducer | ||
| 900 | mm | 3.85 | 6.38 | 6.71 | 8.75 | 5.50 |
| 750 | mm | 3.30 | 5.48 | 5.78 | 7.54 | 4.95 |
| 600 | mm | 2.75 | 4.82 | 5.06 | 6.60 | 4.40 |
| 450 | mm | 2.09 | 3.66 | 3.85 | 5.01 | 3.85 |
| 300 | mm | 1.65 | 2.89 | 3.03 | 3.96 | 3.30 |
| 200 | mm | 1.38 | 2.41 | 2.53 | 3.30 | 2.75 |
| 150 | mm | 1.38 | 2.41 | 2.53 | 3.30 | 2.75 |
ACCESSORIES
| Width of Cable Tray | Manhours per Linear Meter | |||||
|---|---|---|---|---|---|---|
| Connector Plates | Expansion Joint | Dropouts | Cable Separator | Blind Ends | ||
| 900 | mm | 1.00 | 7.70 | 3.30 | 1.00 | 1.93 |
| 750 | mm | 1.00 | 6.88 | 2.75 | 1.00 | 1.65 |
| 600 | mm | 1.00 | 6.05 | 2.20 | 1.00 | 1.38 |
| 450 | mm | 1.00 | 5.23 | 1.93 | 1.00 | 1.10 |
| 300 | mm | 1.00 | 4.40 | 1.65 | 1.00 | 1.10 |
| 200 | mm | 1.00 | 3.30 | 1.38 | 1.00 | 0.55 |
| 150 | mm | 1.00 | 2.75 | 1.38 | 1.00 | 0.55 |
